WL-TW10-4K-IR pairs a 2 MP visible channel with 640 × 512 thermal imaging. Selection follows the retained specification; the model suffix does not establish another output resolution.
WL-TW10-4K-IR uses a 2 MP visible channel and 640 × 512 thermal imaging. Its retained table lists 52× visible zoom, a 50 mm thermal lens, continuous pan, RS485, ONVIF Profile S/G, IP66 and wiper support; the narrative states 12 V vehicle power. The supplied model name is retained without interpreting the suffix.
Select WL-TW10-4K-IR around retained 2 MP/thermal build. Define that task before comparing options.
Build the operator sequence around retained 2 MP/thermal build; state the view, detail and mode change needed.
Vehicle or marine surveillance, law-enforcement and emergency fleets, fire-control vehicles, ambulances and power-line observation are listed uses. The retained 2 MP/thermal configuration, not the application label, controls the selection.
Put 8 kg movement envelope on the drawing and leave unresolved mechanics pending.
Map DC 12 V, web and RS485 to host functions one by one rather than relying on names.
Check installed power and cabling; keep 4K suffix meaning separate until confirmed.
Send retained 2 MP/thermal build, 8 kg movement envelope and DC 12 V, web and RS485; flag 4K suffix meaning for confirmation.
| Model No. | WL-TW10-4K-IR |
| Visible Camera | |
| Image Sensor | 1/2.8” Progressive Scan CMOS |
| Effective pixels | 1920(H) x 1080(V), 2 Megapixels; |
| Minimum Illumination | color:0.0005 Lux @(F1.4,AGC ON);B/W:0.0001Lux @(F1.4,AGC ON) |
| Focal Length | 6.1-317mm |
| Optical Zoom | Optical Zoom 52x, 16x digital zoom |
| Aperture Range | F1.4-F4.7 |
| Horizontal field of view | 61.8-1.6°（wide-tele） |
| Minimum Working distance | 100mm-2000mm (wide-tele) |
| Zoom speed | Approximately 5s(optical lens, wide to tele) |
| Video Compression | H.265 / H.264 / MJPEG |
| Interface Protocol | ONVIF(PROFILE S,PROFILE G) |
| Smart detection | Cross-border detection, area intrusion detection, entering / leaving area detection, hovering detection, personnel gathering detection, fast motion detection, parking detection / take detection, scene change detection, audio detection , False focus detection, face detection |
| Thermal imaging | |
| Detector type | Uncooled Vanadium Oxide Detector |
| Resolution/pixel spacing | 640 × 512 |
| Response band | 8~14 μm |
| pixel size | 12 μm |
| Lens | 50mm |
| sensitivity | <35 mk (@25 °C, F# = 1.0) |
| false color mode | White Hot, Black Hot, Fusion 1, Rainbow, Fusion 2, Iron Red 1, Iron Red 2, Sepia, Color 1, Color 2, Ice Fire, Rain, Red Hot, Green Blue, Dark Blue |
| PTZ | |
| Pan preset speed | 100°/s |
| Tilt preset speed | 60°/s |
| Pan control speed | 0°~60°/S |
| Tilt control speed | 0°~40°/S |
| Pan range | 360°endless rotation |
| Tilt range | +90° ~ -90° |
| Preset positions、Tracking | 256 positions 8 tracking |
| Control Way | RS485, Built-in PELCO D/P 16 protocol, Baud Rate from 2400Bps to 19200Bps optional |
| Relative Humidity | Less than 90% |
| IP Grade | IP66 |
| Working Temperature | -35° ~ +55° |
| Wiper | Support |
| Weight | 8kg |
The Vehicle PTZ Camera category provides the relevant product group for WL-TW10-4K-IR. Base the comparison on the retained 2 MP and thermal specification, DC 12 V supply, drawing and required web or RS485 functions.
Begin with retained 2 MP/thermal build.
Check DC 12 V, web and RS485 against required host functions.
Show 8 kg movement envelope, cables and clearances.
Keep 4K suffix meaning unresolved until written confirmation.
Selection must follow the values actually shown on the page: a 2 MP visible channel with 52× optical zoom and a 640 × 512 thermal channel with a 50 mm lens. The model name remains unchanged, but it is not evidence for a different output resolution. Compare the required visible and thermal views against this retained build.
Place the 8 kg load and continuous-pan movement envelope on the vehicle or marine support drawing. The dimension image, cable exit, wiper area and nearby structures need to be reviewed together. A support that carries the static load but obstructs movement is not a complete layout.
The page identifies DC 12 V power, web access, RS485 and ONVIF Profile S/G. Assign the required controls to those paths and show the supply at the camera connection. Any interpretation of the model suffix stays out of the purchase description unless a separate confirmed specification is provided.
Compare the inquiry with the standard table one last time. Visible resolution, thermal resolution, lens, weight and control route should all describe the same WL-TW10-4K-IR configuration. Keep optional combinations separate and do not use the model name to replace a stated page value.
If the project needs another visible resolution, request it as a separate configuration with its own supporting specification. Do not alter the retained 2 MP baseline by interpretation.
Use Contact Us to send retained 2 MP/thermal build, the drawing and required functions. Identify 4K suffix meaning as pending.
